XJ450 WORKOVER RIG

REFURBISHED XJ450 WORKOVER RIG HOT SALE



Model/PN: XJ450 WORKOVER RIG

Brand: TOPLAND

Standard: API

Warranty: 12 Months

Place of Origin: China

Application: Oilfields equipments & Spares

Packaging: Export Standard Packing

HS code: 8431499900

Workover Depth: 5500m

Hook load: 1100KN

Mast Height: 32M

Color: Red, Can be customerized



Product Details

REFURBISHED XJ450 WORKOVER RIG HOT SALE


The XJ450 is a heavy-duty truck-mounted workover rig engineered for deep well servicing and light drilling operations. With a maximum static hook load of 1,100 kN and a workover depth capability of 5,500 m, it delivers reliable performance in the most demanding oilfield environments.

Main Specification:

1.Workover Depth: 5500 m (for 27/8 in tubing)

2.Heavyduty Workover Depth: 4500 m (for 31/2 in drill pipe)
3.Maximum Hook Load: 1100 KN
4.Hoisting System Roping: 4×5
5.Drilling Wire Rope Diameter: Φ26 mm (1 inch)
6.Effective Mast Height: 32 m
7.Drawworks: Double Drum Maximum Fastline Pull of Main Drum on the 2nd Layer: 210 KN
8.Chassis Drive Configuration: 10×6

9.Ambient Temperature Range: 20℃ ~ +45℃


Applications:
Designed for high-depth well servicing, heavy-duty tubing and rod replacement, downhole maintenance, fishing, and recompletion. The rig is also suitable for shallow to medium-depth drilling and is ideal for remote oilfields and harsh operating environments.

Features:

  • Hydraulic lifting and telescoping derrick for rapid rig-up/rig-down

  • Single or dual drum drawworks configurations available

  • Positive and reverse rotary table drive with anti-reverse torque release device for enhanced safety

  • Optional automated pipe handling systems for improved efficiency and reduced labor intensity

Built to deliver consistent performance, the XJ450 combines robust construction with operational flexibility for today‘s oilfield service demands.
