CEMENTING HEAD 9 5/8" _Welcome to Topland Oilfield

Cement Head is a special tool for pumping slurry and releasing plug. It makes the drilling fluid fill into casing in turn and quickly.

Connect casing string and cementing manifold.

Features of Cementing Head

1. Quick-latch adapter is designed to offer easier, faster and safer makeup for two-stage cementing. It is manufactured utilizing API grade steels with connections for API 8 round, buttress and premium threads.

2. Double balance pipe is developed.

3. Positive lever indicates plug releasing.

4. Main parts are made from AISI 4145H alloy steel.

5. Top cover and union nut with large trapezoidial-threaded, it makes the tool convenient to disassemble and carry.

Type of Cement Heads:

1. Drill pipe cement heads

2. Liftable drill pipe cement heads

3. Integral Ultrahigh pressure drill pipe cement heads

4. Simple casing cement heads

5. Quick change casing cement heads

6. Integral quick change casing cement heads

Type	127	177.8	244.5	339.7
	(5″)	(7″)	(95/8″)	(133/8″)
Max rated pressure (MPa)	35	35	35	21
Connecting Thread	BTC	BTC	BTC	BTC
Manifold	2″1502 Union	2″1502 Union	2″1502 Union	2″1502 Union
ID of main body(mm)	113	160	225	320
Length of top plug container(mm)	270	270	290	375
Length of bottom plug container(mm)	270	270	290	375
Total length(mm)	1686	1718	1993	2152

Model/PN:CEMENTING ...	13 3/8" CEMENT HEAD DOUBLE PLUG TYPE, WITH WORKING PRESSURE 10,000-15,000 PSI, WITH SHORT ROUND THRE... Brand:	Unit: EA Lead Time: 40 Days	Price(USD) $ *2500.00
Model/PN:CEMENTING ...	9 5/8" CEMENT HEAD DOUBLE PLUG TYPE, WITH WORKING PRESSURE 10,000-15,000 PSI, WITH SHORT ROUND THREA... Brand:	Unit: EA Lead Time: 40 Days	Price(USD) $ *0763.89
Model/PN:CEMENTING ...	9 5/8" SINGLE PLUG CEMENTING HEAD, CEMENT HEAD SHOULD INCLUDE AN INTEGRAL QUICK - LATCH COUPLER THAT... Brand:	Unit: EA Lead Time: 60 Days	Price(USD) $ *523.09
Model/PN:SINGLE PLU...	13 3/8" SINGLE PLUG CEMENTING HEAD, AN INTEGRAL QUICK - LATCH COUPLER THAT ALLOWS SAFE AND INSTALLAT... Brand:	Unit: EA Lead Time: 60 Days	Price(USD) $ *162.85

9 5/8" SINGLE PLUG CEMENTING HEAD, CEMENT HEAD SHOULD INCLUDE AN INTEGRAL QUICK - LATCH COUPLER THAT ALLOWS SAFE AND INSTALLATION AND ELIMINATES CONNECTION FROM THE PLUG CONTAINER / CASING ASSEMBLY., THE QUICK LATCH COUPLER UNIT SHOULD LOCKS AND SEAL CEME

**US$ *523.09EA**
