The TOPLAND's gate valve features a non-rising stem with a slab gate, Full-Bore Thru-Conduit Design, Floating Slab Gate and Seats, floating seat ring body bushing design to provide safe dependable service. It is available in flanged or threaded ends in standard bore sizes from 1-13/16` thru 7-1/16` in working pressures of 5, 000 psi thru 15, 000 psi wp. Seat rings, body bushings, gate, stem are easily replaced in the field, Simple routine maintenance program limits repairs, eases operation, protects against corrosion, and extends service life.
- Pressure rating, 5000PSI to 15000PSI
- Type: TLC / TLL(equivalent to Cameron FC / FL)
- Operations: Manual / Hydraulic / BSO(Ball Screw Operated)
- Material classes. DD to FF
- Temperature, PU, LU
- Interchangeability: 100%
- PSL 2 to 3 and PR 1 & 2
The TOPLAND's expanding gate valve features a non-ring stem with an expanding gate design to provide safe, dependable service in a variety of environments, It’s a available in flanged or threaded ends in standard bore sizes from 2-1/16” thru 4-1/16” in working pressures of 3000psi thru 5000psi. Full-Bore Design: Maximizes valve service life.
- Pressure rating, 3000PSI to 5000PSI
- Operations: Manual
- Type: TLM(equivalent to WKM)
- Material classes. DD to FF
- Temperature, PU, LU
- PSL 2 to 3 and PR 1 & 2
The TOPLAND's mud gate valve, with superior design features precision workmanship and a proven principle are engineered to meet the harsh driling requirements in today’s oilfeld.
The TLD valve conforms to the standard flange dimensions and pressure rating of 3000 and 5000PSI working pressure, and temperature sercive to 400℉. The valve standard trim includes 316SS gates 316SS stems and Buna N seats,optional trims are available which include Ni Plated Carbon Steel, Monel, and Aluminum Bronze gates. Seats are offered in Viton and Hypalon and optional 303SS stem is available.
- Size Range: 2” 3” 4” 4x5”
- Connection: Flanged, Screwed, Weld.
- Pressure rating, 3000PSI to 5000PSI
- Type: TLD(equivalent to Demco gate valve)
- Operations: Manual
The TLO gate valve, provide easy operation, tight shut offs, long periods before overhaul. This assures simple, fast, low cost renewal in the field. Standard gate packing are designed for a wide range of fluids,special rubber compounds on request for additional versatility.Ability to change valve subs in the field, eliminates the expense of replacing the valve body.
Extra large ball bearing and heavy duty stem threads,minimizes torque required for operation of the valve.
- Size Range: 2” 3” 4”
- Connection: Flanged, Screwed, Weld.
- Pressure rating, 3000PSI to 5000PSI
- Type: TLO(equivalent to Oteco gate valve)
- Operations: Manual
