SUBMERCIBLE SLURRY PUMP MODEL: GN100YZ160A-38B GN SOLIDS CONTROL MAINTENANCE-FREE, HIGH TEMPERATURE RESISTANT

**US$ *1380.21SET**

Model/PN: SUBMERCIBLE SLURRY PUMP

Brand: GN

Standard: API

Lead Time: 30 days

Warranty: 12 Months

Place of Origin: China

Payment Method: T/T

Application: Oilfields equipments & Spares

Packaging: Export Standard Packing

HS code: 8431499900

Size: 3100×750×900

Purchase Quantity

Add to Wishlist

Product Details

The submerged slurry pump produced by Guanneng Solid Control is mainly used in oil drilling mud systems. The device can also be used in environmental protection, municipal engineering, thermal power plants, gas coking plants, oil refineries, steel mills, mining, paper industry, cement Plants, food factories, printing and dyeing industries suck concentrated liquid, heavy oil, oil residue, dirty liquid, mud, mortar, quicksand and flowing sludge from urban sewage channels, as well as fluids containing mud, sand, and corrosive liquids.

The YZ submerged slurry pump is a vertical single-stage single-suction cantilever centrifugal pump structure. The impeller is a semi-open impeller, and a stirring blade is arranged at the extension of the suction side of the impeller. Hebei Guanneng Solids Control is a professional oil drilling fluid submerged slurry pump manufacturer. The main feature of YZ type submerged slurry pump is that the pump shaft in the submerged part has sufficient rigidity. There is no set between the impeller and the pump casing. Bearings do not use shaft seals, which can transport media with a relatively large concentration of solid particles; they are maintenance-free and resistant to high temperatures. The length of the pump inserted into the liquid is between 800-1900mm, and a suction pipe can be equipped if necessary. The transmission is installed on the motor base by a vertical motor and connected with the pump by a coupling. Viewed from the direction of the motor, the pump rotates in a clockwise direction.

SUBMERCIBLE SLURRY PUMP

MODEL: GN100YZ160A-38B

POWER RATE: 30 KW / 1450 RPM / 50 HZ - VFD (VARIABLE SPEED MOTOR)

OUTLET: DIN 100 (4 - INCH)

DIMENSION: 3100×750×900

HDD PIT APPLICATION - SKID FOOT PRINT / LANDING BASE PLATE
